Multi-function Calibration 709H Max voltage 30V Power consumption About 360mA/5V Storage humidity 90% RH loop calibrator(RUOSHUI 709H)
4.6 (60 items)
Limited Time SaleUS$661.00 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210897165 | Release Date | 2026/04/04 | List Price | US$440.67 | Model Number | 210897165 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
RUOSHUI 709H Max voltage 30V Power consumption About 360mA/5V Storage humidity 90%RH loop calibrator 709H with HART communication, Support HART general instructions and general application instructions. Able to read the device basic information, perform diagnostic testing and calibration to fine tune the most HART transmitter, can store up to 20 HART device configuration file. General Specifications Power supply : four 1.5V alkaline batteries(LR6) Battery life : about 360mA /5V under the condition of 20mA with 1kΩ load Max. permitted voltage : 30V(between any two terminals or between any terminal and earth ground) Operating temperature : 0°C～50°C Operating relative humidity : ≤ 80%RH Storage temperature : ≤ - 20°C～60°C Relative humidity for storage : ≤ 90%RH Temperature co-efficiency : 0.1×Basic accuracy/ ℃(Temperature<18℃ or >28℃) Protection level : IP65(Dust,Water spray) Display :3.2 inch TFT color display Size : 206(L)×97(W)×60(D)mm Weight : 600g Safety : EN61010-1:2001 Accessories : The test pen(H000000-00) Industrial test lead(H000002-00) Crocodile clip(H010000-00) VC709H Quick guide_English(E100073-00) VC709H Product qualification certificate_ English(E300018-00) VC709H Product user manual _ English(E400022-00) Insurance tube(D610000-00) 5alkaline battery(D620002-00) Option PC infrared communications accessories package(Z070102-0000-00) Linear power adapter(DC5V)(P070003-00) Hook type tester(H000004-00)
- Max voltage 30V Power consumption About 360mA/5V Storage humidity 90%RH loop calibrator
- 709H with HART communication, Support HART general instructions
- Electrical safety EN61010-1:2001 EMC EN61326-1:2006
- Perform diagnostic testing and calibration to fine tune the most HART transmitter
- Protection level : IP65(Dust,Water spray) Display :3.2 inch TFT color display
| Color | Orange |
|---|---|
| Model | EO-RUOSHUI 709H |
| Brand Name | RuoShui |
| Style Name | Process Calibrator |
| Unit Count | 1.0 Count |
| Item Length | 15 Centimeters |
| Item Weight | 1 Kilograms |
| Part Number | EO-RUOSHUI 709H |
| Manufacturer | Xi'an Beicheng Electronics Co.Ltd(RUOSHUI) |
| Power Source | Battery Powered |
| Response Time | 1 seconds |
| Specification Met | CE, RoHS, UL |
| Included Components | RUOSHUI 709H |
| Upper Temperature Range | 60 Degrees Celsius |
| EU Spare Part Availability Duration | 1 Years |
